Single Mast Push Around Vertical Lift

Single Mast Push Around Vertical Lift Specification

Usage
Building Elevator

Type
Lifts

Material
Iron, Galvanized Steel

Drive Type
Hydraulic

Control Device
Calling Box

Single Mast Push Around Vertical Lift Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA)

Supply Ability
10 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Single Mast Push Around Vertical Lift

Single Mast Push Around Vertical Lift is a compact, portable lifting device that is designed for indoor use in tight spaces. It is ideal for maintenance and repair work, inventory management, and general construction. The lift features a single mast that provides a maximum working height of up to 5 meters, with a weight capacity of up to 150 kg. The lift is operated manually and is equipped with a locking brake system that keeps it in place during use. Single Mast Push Around Vertical Lift can be easily transported from one location to another and can be set up quickly and easily, making it a versatile and cost-effective lifting solution.

Specifications

Brand	Dingli by Mtandt
Installation	Not Provided
Work Surface	Stainless Steel
Model Name/Number	GTWY11-1300 / GTWY9.5-1300
Working Height	9.5m-14m
Platform Width	0.75m
Type Of Mast	Single Mast
Load Capacity	200-250 kg
Usage/Application	Construction

Size

Model	GTWY11-1300	GTWY9.5-1300
Max.Working Height A	11.00m	9.50m
Max. Platform Height B	9.00m	7.50m
Overall Length(Stowed) C	1.34m	1.30m
Overall Width E	0.75m	0.75m
Overall Height F	1.99m	1.99m
Outrigger Footprint(H/I)	1.70m/1.86m	1.70m/1.86m
Platform Size(Lenth/Width)	0.70mx0.60m	0.70mx0.60m
Ground Clearance	55mm	55mm
